Install the Power Module breaker onto the backup controller.
Plug a breaker (Eaton BR2100, not included) on the rail labeled Power Module, and then secure the breaker using a screw (M3×75 mm, included).
Figure: Install the Power Module 1 breaker.
2. Flexible solution
The maximum output current of a single Power Module is 25A, and one circuit breaker inside the Backup Controller can connect up to 3 Power Module units.
Installers can select the circuit breaker specifications based on actual site conditions, rather than strictly following Anker’s recommendation of using Eaton BR2100.
The number of Power Modules connected to a circuit breaker
